Featuring

  • Internationally recognised symbols
  • Internal/external use
  • UV protected
  • Easy installation
  • Vandal resistant

Location of Braille and Tactile Signs

Signs including symbols, numbering and lettering must be designed and installed as follows:

  1. Signs must be located not less than 1200mm and not higher than 1600mm above the floor or ground surface.
  2. Signs with single lines of characters must have the line of tactile characters not less than 1250mm and not higher than 1350mm above the floor or ground surface.
  3. Signs identifying rooms containing features or facilities listed in D3.6 must be located:
    1. on the wall on the latch side of the door with the leading edge of the sign located between 50mm and 300mm from the architrave
    2. in the event of insufficient latch side dimension, a sign may be placed on the non-latch side of the door
    3. where (i) and (ii) is not possible, the sign may be placed on the door itself.
  4. Signs identifying paths of travel must be placed so they are located directly ahead in the direction of travel.  Where one wall continues in the direction of travel and the other forms a corner, the sign must be place on the continuing wall.

Compliance specs for our signs

  • All signs are manufactured from PVC to a depth of 3mm (Because of the thickness no backing panel is required)
  • All signs are injection moulded so that all graphics are of a continuous nature for hygiene purposes as set out in Building Code of Australia BCA section D3.6
  • Moulded signs mean that adhesive failure on symbol, letters and braille dots is impossible which in turn extends the life of each sign
  • Sign sizes are 180mm x 180mm x 3mm or 180mm x 210mm x 3mm depending on content
  • Silver signs are coated with a micro metallic silver acrylic lacquer to give the appearance of clear anodized aluminium
  • Tactile character & symbols have a minimum 30% luminance–contrast with the background
  • Complies with The Building Code of Australia (Section D3.6)
  • Complies with Design for Access and Mobility (AS1428.1-2011)
  • Complies with Public Information Symbol Signs (AS2899.1-1986)
SizeQuantity FromQuantity ToPrice
210x180 mm - BLue14$ 55 $ 41
59$ 50 $ 38
1019$ 45 $ 34
2049$ 40 $ 30
50200$ 30 $ 23
210x180 mm - Silver14$ 55 $ 41
View More
Loading...

We will provide the preprinted Text as displayed below.  If you want to customize the Text then Select "YES" and Enter your text in below Box.



Total$ 55 $ 41
